400A AC/DC Pulse TIG / ARC Welder – Optional Water Cooled Set Up
Original price was: $7,584.25.$758.43Current price is: $758.43.
Strata 400A Three-Phase Synergic AC/DC Pulse TIG/ARC PFC Inverter Welder – AdvanceTig400ACDC
Results speak for themselves, achieved with top level features such as adjustable arc force, AC wave and a program saving function. Strata welders are for those who demand reliability, versatility, and performance at the highest levels.
The AdvanceTig Series are at the top of their class featuring state-of-the-art IGBT technology.
With a formidable 400A output and three-phase power, this machine is designed for high-demand use in tough situations including all workshops and onsite tasks.
Features:
Max Output (Tig/Arc) – 400A
Max Electrode Size – 4.0mm
Input Power Supply – 400V Three Phase 32A
Full Colour LCD Control Screen – Intuitive and clear visibility and setting of control parameters.
IGBT module inverter technology for smooth and stable output, increased reliability and high duty cycle.
TIG Smart Set Synergic Mode – Easy setting of welding parameters according to material, thickness and joint type.
Spot Welding Mode – special feature for welding very thin material without heat distortion.
Active PFC Technology – Increased duty cycle and energy efficiency. Can be safely used with long extension lead.
20 Memeory Settings – Ability to quickly save and recall control settings for specific jobs.
AC Sine, Square, Triangle & Mixed AC Wave Options – Ultimate control for every AC tig welding application.
AC/DC Mix and Enhanced Fusion Feature -Faster AC TIG welding speeds
Digital Microprocessor Control System for superior and dynamic arc characteristics. – Accurate and reliable setting of control parameters.
Lift TIG and HF start modes for versatility when welding around sensitive electronic equipment.
2T / 4T and Bi-Level Trigger Control Modes – Ease of operator use for all job applications.
Electronic HF TIG arc ignition system for contamination free and easy arc starting with low EMF interference.
Phase loss protection for automatic shut down if power supply phase loss occurs, to prevent damage.
IP23 Industrial damage resistant industrial casing with front panel protection.
Adjustable arc force, hot start and automatic anti stick control for greater control and ease of use for MMA welding.
Extreme stress testing to 550v in production to ensure rugged reliability.
High quality and over specified electronic components for durability & reliability.
Lightweight and compact design ideal for portable applications.
Designed to work with generator power supply and protect from power surges. (Min Req 25kVA)
Quick connect inlet gas fitting for ease of use and changing of gas bottles.
Optional Extras:
Wired and Wireless Foot Pedal Control Option.
Dual Mode Remote Control Option – Digital up / down button or potentiometer thumb wheel torch remote control options through a single connection plug.
Accessories Include:
5m ARC Lead
5m Earth Lead
Strata Professional PRO18 TIG torch.
2-Stage Flowmeter Argon Gas Regulator.
2m QC Gas Hose Kit.
Water Cooled Package Includes:
Integrated Modular Design Trolley
Easy connection of water-cooled torch with low coolant torch protection function.
Strata Professional Water Cooler
Model: AdvanceTig400ACDC
Specifications:
| Input Power Supply: | 400V AC 3 Phase 32A 50/60Hz |
| Maximum Input Current: | 36.5A |
| Generator Capacity: | 25KVA |
| TIG Pulse Frequency: | 0.5 – 999Hz |
| AC TIG Waveform: | Square, Sine Triangular, Multi wave |
| AC Frequency Adjustment: | 50 – 250Hz |
| Standards: | AS/ IEC60974-1:2012 |
| ACDC TIG Current Output: | 10 – 400A |
| Duty Cycle MMA + DC TIG/AC: |
400A @ 60% 310A @ 100% |
| AC TIG Duty Cycle |
400A @ 60% 310A @ 100% |
| Dimensions: | 640 x 250 x 500mm |
| Weight: | 27kg |
Click Here For More Information
Click Here For User Manual Here
All Prices Include GST
